| Place of Origin: | China |
| Model Number: | GS-05 |
| Minimum Order Quantity: | 50PCS |
|---|---|
| Price: | US$1,50 - US$200,00 |
| Packaging Details: | white box, color box, blister, color card with blister, double blister with color card, brown box, ect. |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 10000pcs per day |
| Application: | Scoring | Arbor Size: | 30mm |
|---|---|---|---|
| Blade Diameter: | 300mm | Blade Material: | Carbide-Tipped |
| Compatibility: | Circular Saws | Grind: | TCG |
| Hook Angle: | -5 Deg. | Kerf: | 3.2mm |
| Maximum RPM: | 7,000 RPM | Noise Level: | Low |
| Number Of Teeth: | 96 | Plate Thickness: | 2.2mm |
| Tooth Design: | Flat Top |
300mm Diameter 30mm Hole 96T TCT Circular Saw Blades For Scoring Plastic In General And FRP
The TCT Circular Saw Blades (Sierras Circulars) are designed as plastic cutting blades that suitable for cutting plastic material in general, such as plexiglass (FRP), solid suface and PVC etc…
The blades are also suitable for ripping & cross cutting laminates & Bi-laminates, veneered or plastic coated board.
Quality: for indutrial and professional market
Diameter: 300mm
Kerf: 3.2mm
Plate thickness: 2.2mm
Bore: 30mm
Teeth number: 96
Teeth type: ATB, TCG
Other sizes and specifications:
| Diameter (mm) | Kerf (mm) | Body Thickness (mm) | Teeth number | |
| 125 | 2.6 | 1.6 | 30,32 | |
| 150 | 2.6 | 1.6 | 36,40,42 | |
| 165 | 2.6 | 1.6 | 40,46 | |
| 180 | 2.8 | 1.8 | 44,50 | |
| 200 | 2.8 | 1.8 | 56,60 | |
| 216 | 2.8 | 1.8 | 56,60 | |
| 230 | 2.8 | 1.8 | 60, 64, 80 | |
| 250 | 3.0 | 2.0 | 72,80, 96, 100 | |
| 300 | 3.2 | 2.2 | 72,84,96, 100, 120 | |
| 350 | 3.2 | 2.2 | 84,96, 100, 108, 120 | |
| 400 | 3.5 | 2.5 | 96,108,112, 120 | |
| 420 | 3.5 | 2.5 | 96,108,112, 120 | |
| 450 | 3.5 | 2.5 | 108,120, 140 | |
| 500 | 3.5 | 2.5 | 120,132, 140 | |
| 550 | 3.8 | 2.8 | 132,144, 160, 180 | |
|
4.0 | 3.0 | 140, 160, 180 | |
| 650 | 4.0 | 3.0 | 140, 160, 180 | |
| 700 | 4.2 | 3.2 | 140, 160, 180 | |
| 750 | 4.6 | 3.6 | 140, 160, 180 |
Remark: Other special izes and specification can be tailor-made for our clients.
