| Place of Origin: | China |
| Nom de marque: | LUXU |
| Certification: | TUV |
| Model Number: | LXR0222-834-001 |
| Minimum Order Quantity: | 50PCS |
|---|---|
| Prix: | US$1,50 - US$200,00 |
| Packaging Details: | white box, color box, blister, color card with blister, double blister with color card, brown box, ect. |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 10000pcs per day |
| Name: | Diamond Saw Blade Blank | Tooth pitch: | Laser cut or punched |
|---|---|---|---|
| Teeth: | Sharpened | Color: | Natural |
| Function: | for making diamond saw blade | Slot type: | key, U shape |
| Surface treatment: | Oiled or painted | Body material: | 65Mn |
| Thickness: | 4.6mm | Diameter: | 834mm |
| Bore diameter: | 30mm |
L'écartement de la lame de scie à diamant - L'écartement de la lame circulaire - 834 mm x 4,6 mm x 30 mm
Pour la fabrication de lames de scie à diamants de taille 850 mm
Qualité: pour le marché industriel et professionnel
Forage: toutes tailles et sur demande, y compris 5/8 ", 1 ", 20 mm, 22,23 mm, 25 mm, 30 mm, 35 mm.
Type de fente:
Autres tailles et spécifications:
| Diamètre de la lame de diamant (mm) | Noyau en acier vierge | Épaisseur du noyau en acier (mm) | |||||
| Diamètre (mm) | |||||||
| 230 | 214 | 210 | 1.6 | 1.8 | 2 | ||
| 250 | 234 | 230 | 1.6 | 1.8 | 2 | ||
| 300 | 284 | 280 | 1.8 | 2 | 2.2 | ||
| 350 | 334 | 330 | 2 | 2.2 | 2.4 | ||
| 400 | 384 | 380 | 2.2 | 2.4 | 2.6 | 2.8 | 3 |
| 450 | 434 | 430 | 2.4 | 2.6 | 2.8 | 3 | |
| 500 | 484 | 480 | 2.6 | 2.8 | 3 | 3.2 | |
| 550 | 534 | 530 | 2.8 | 3 | 3.2 | 3.4 | |
| 600 | 584 | 580 | 3 | 3.2 | 3.4 | 3.6 | |
| 650 | 634 | 630 | 3.2 | 3.4 | 3.6 | 3.8 | |
| 700 | 684 | 680 | 3.4 | 3.6 | 3.8 | 4 | |
| 750 | 734 | 730 | 3.6 | 3.8 | 4 | 4.2 | |
| 800 | 784 | 780 | 3.8 | 4 | 4.2 | 4.4 | |
| 850 | 834 | 830 | 4 | 4.2 | 4.4 | 4.6 | |
| 900 | 884 | 880 | 4.5 | 5 | 5.5 | 6 | |
| 1000 | 984 | 980 | 5 | 5.5 | 6 | 6.5 | |
| 1100 | 1084 | 1080 | 5.5 | 6 | 6.5 | 7 | |
| 1200 | 1184 | 1180 | 5.5 | 6 | 6.5 | 7 | |
